100A Siemens Neutral Assembly ID Switch

Siemens 100A Neutral Assembly Kit designed for ID Switches

Safety Switch, Non-Fusible, Duty Heavy, Amps 100, Voltage 600V, Phase Single or Three, HP 100, NEMA Rating 3R, Material of Construction Steel, Number of Wires 3, Number of Poles 3, Contact Form 3PST, Neutral Assembly HN263
AC Voltage Rating 480/600 V
Actuator Lever
Amperage 100 A
Amperage Rating 100A
Amps 100
Application Construction, Industrial, Residential
Catalog Description 100A 3P 600V 3W NON-FUSED HD TYPE 3R
Catalog Number HNF363R
Commodity Code 3100
Contact Form 3PST
Country of Origin MX
DC Voltage Rating 250/600 V
Depth (in.) 14.5
Duty Heavy
EU RoHS Indicator C
Enclosure Type 3R
Environmental Conditions Seismic T58569.01-1
Fuse Provision Non Fusible
GTIN 00783643151758
Gross Weight 20.000 L
Height 8.0000 IN
Height (in.) 8
Hp 100
In Stock Yes
Invoice Description English 100A 3P 600V 3W NON-FUSED HD TYPE 3R
Length 25.8000 IN
Material Galvanized Steel
Material of Construction Steel
Mfr/Vendor Siemens
Model HNF
Mounting 2 or 3 Point Mounting
NEMA Rating 3R
Neutral Assembly HN263
Neutral Type No
Number of Poles 3
Number of Wires 3
Operating Cycles UL 98 Cycles
Phase Single or Three
Power Rating 15 Hp At 240 VAC 1 Phase, 30 Hp At 480 VAC 1 Phase, 40 Hp At 600 VAC 1 Phase/240 VAC 3 Phase, 75 Hp At 480 VAC 3 Phase, 100 Hp At 600 VAC 3 Phase, 20 Hp At 250 Vdc, 25 Hp At 600 Vdc
Product Type Safety Switch
ShipWeight 20.00
ShortDescriptionStripped Siemens-HNF363R-ITE-3P-600V-100A-Safety-Switch
Special Features Non Fusible
Standard UL98
Standards UL
Type Safety Switch, Enclosed Heavy Duty
UPC 783643151758
Voltage 600
Voltage Rating 600V
Weight 20.76
Width 13.9000 IN
Width (in.) 26
description S-A HNF363R 100A 3P 600V 3W NON-FUS
