60Amp 600V 3-Pole 3-Wire Siemens Heavy Duty Fusible Type 12, Safety Switch with Window

Description:
30–600A, 3-pole 600V max. in fusible and non-fusible versions in Type 4/4X stainless
steel and Type 12 enclosures. All allow viewing of visible blade position. 30–200A also allow viewing of indicating type fuses.

Features:
• Rugged installer-friendly enclosure design features a gasket flange with continuously welded seams
• Tool-free cover latches
• Two, three and four point mounting
• Metal handle with large insulating grip features a positive stop in both ON and
OFF position
• Ground lugs provided as standard
• Type 12 enclosures are fabricated from galvanized steel and are also rated for
3R/3S outdoor applications
• Type 4X stainless steel switches (30–200A) are 304 grade stainless steel
and are provided with stainless steel interior parts
• The widest range of accessories available including 200% neutrals, gold plated PLC auxiliary contacts and isolated ground kits

Type 12 enclosures are intended for indoor use primarily to provide a degree of protection against dust, falling dirt and dripping water. They are not intended to provide
protection against conditions such as internal Command.
