30A 120/277V Pass & Seymour® Industrial Extra Heavy-Duty Specification Grade Switch, Brown
$68.83
In stock
SKU
PASPS30AC3
Switch industrial extra heavy-duty specification grade features heavy-gauge one-piece copper alloy contact arm virtually eliminates contact bounce. Cam controls fast make and positive break to minimize arcing.
Industrial Extra Heavy-Duty Specification Grade Switch, Brown.
Features & Benefits:
- External screw-pressure-plate back and side wired. Accepts #14 - #10 AWG copper or copper-clad conductors.
- Heavy-gauge one-piece copper alloy contact arm virtually eliminates contact bounce.
- Cam controls fast "make" and positive "break" to minimize arcing.
- Heavy-duty bumper pads for quiet operation.
- High strength thermoplastic polycarbonate toggle.
- Back body made of glass-reinforced nylon.
- Locking support provides resistance to face and back body separation.
- Oversized silver alloy contacts for long life and better heat dissipation.
- Grounding terminal is standard.
- Shallow design for ease of installation.
- Strap nickel-plated steel with integral ground.
- Auto-ground clip assures positive ground.
Features & Benefits:
- External screw-pressure-plate back and side wired. Accepts #14 - #10 AWG copper or copper-clad conductors.
- Heavy-gauge one-piece copper alloy contact arm virtually eliminates contact bounce.
- Cam controls fast "make" and positive "break" to minimize arcing.
- Heavy-duty bumper pads for quiet operation.
- High strength thermoplastic polycarbonate toggle.
- Back body made of glass-reinforced nylon.
- Locking support provides resistance to face and back body separation.
- Oversized silver alloy contacts for long life and better heat dissipation.
- Grounding terminal is standard.
- Shallow design for ease of installation.
- Strap nickel-plated steel with integral ground.
- Auto-ground clip assures positive ground.
| SKU | PASPS30AC3 |
|---|---|
| Amperage | 30A |
| Application | Designed for industrial applications |
| Bestseller | No |
| Brand | Pass & Seymour |
| Certification | CSA certified, UL listed |
| Color | Brown |
| Dimension Height | 3.281 in |
| Dimension Width | 1.32 in |
| Featured | No |
| Material | Thermoplastic Polycarbonate |
| Manfacturer Part No. | PS30AC3 |
| Poles | 3-way |
| Sales Unit | EA |
| Voltage | 120/277VAC |
